Powered Parachute Flying Handbook


Chapter 9 — Ground Reference Maneuvers

S-Turns Across a Road

An S-turn across a road is a practice maneuver in which the powered parachute’s ground track describes semicircles of equal radii on each side of a selected straight line on the ground. [Figure 9-5] The straight line may be a road, fence, railroad, or section line that lies perpendicular to the wind, and should be of sufficient length for making a series of turns. A constant altitude should be maintained throughout the maneuver; do not go lower than 200 feet.

S-turns across a road present one of the most elementary problems in the practical application of the turn and in the correction for wind drift in turns. The application of this maneuver is considerably less advanced in some respects than the rectangular course. However it is taught after the student has been introduced to the rectangular course in order that he or she may have a knowledge of the correction for wind drift in straight flight along a reference line, before attempting to correct for drift by applying a turn.

The objectives of S-turns across a road are to develop the ability to compensate for drift during turns, orient the flightpath with ground references, follow an assigned ground track, arrive at specified points on assigned headings, and divide the pilot’s attention. The maneuver consists of crossing the road at a 90° angle and immediately beginning a series of 180° turns of uniform radius in opposite directions, re-crossing the road at a 90° angle just as each 180° turn is completed.

To accomplish a constant radius ground track requires a changing rate of turn and angle of bank to establish the wind correction angle. Both will increase or decrease as groundspeed increases or decreases.

The bank must be steepest when beginning the turn on the downwind side of the road and must be shallowed gradually as the turn progresses from a downwind heading to an upwind heading. On the upwind side, the turn should be started with a relatively shallow bank and then gradually steepened as the powered parachute turns from an upwind heading to a downwind heading. In this maneuver, the powered parachute should be rolled from one bank directly into the opposite just as the reference line on the ground is crossed.

Before starting the maneuver, a straight ground reference line or road that lies 90° to the direction of the wind should be selected, then the area should be checked to ensure that no obstructions or other aircraft are in the immediate vicinity. The road should be approached from the upwind side, at the selected altitude on a downwind heading. When directly over the road, start the first turn immediately. With the powered parachute headed downwind, the groundspeed is greatest and the rate of departure from the road will be rapid; so the roll into the bank must be fairly rapid to attain the proper wind correction angle. This prevents the powered parachute from flying too far from the road and from establishing a ground track of excessive radius. During the latter portion of the first 90° of turn when the powered parachute’s heading is changing from a downwind heading to a crosswind heading, the groundspeed becomes less and the rate of departure from the road decreases. The wind correction angle will be at the maximum when the powered parachute is headed directly crosswind.

After turning 90°, the powered parachute’s heading becomes more and more an upwind heading, the groundspeed will decrease, and the rate of closure with the road will become slower. If a constant steeper bank were maintained, the powered parachute would turn too quickly for the slower rate of closure, and would be headed perpendicular to the road prematurely. Because of the decreasing groundspeed and rate of closure while approaching the upwind heading, it will be necessary to gradually shallow the bank during the remaining 90° of the semicircle, so that the wind correction angle is removed completely and the wing becomes level as the 180° turn is completed at the moment the road is reached.

At the instant the road is being crossed again, a turn in the opposite direction should be started. Since the powered parachute is still flying into the headwind, the groundspeed is relatively slow. Therefore, the turn will have to be started with a shallow bank so as to avoid an excessive rate of turn that would establish the maximum wind correction angle too soon. The degree of bank should be that which is necessary to attain the proper wind correction angle so the ground track describes an arc the same size as the one established on the downwind side.

Since the powered parachute is turning from an upwind to a downwind heading, the groundspeed will increase and after turning 90°, the rate of closure with the road will increase rapidly. Consequently, the angle of bank and rate of turn must be progressively increased so that the powered parachute will have turned 180° at the time it reaches the road. Again, the rollout must be timed so the powered parachute is in straight-and-level flight directly over and perpendicular to the road.

Throughout the maneuver a constant altitude should be maintained, and the bank should be changing constantly to affect a true semicircular ground track.

Often there is a tendency to increase the bank too rapidly during the initial part of the turn on the upwind side, which will prevent the completion of the 180° turn before re-crossing the road. This is apparent when the turn is not completed in time for the powered parachute to cross the road at a perpendicular angle. To avoid this error, the pilot must visualize the desired half circle ground track, and increase the bank during the early part of this turn. During the latter part of the turn, when approaching the road, the pilot must judge the closure rate properly and increase the bank accordingly, so as to cross the road perpendicular to it just as the rollout is completed.

Common errors in the performance of S-turns across a road are:

• Failure to adequately clear the area.
• Gaining or losing altitude.
• Inability to visualize the half circle ground track.
• Poor timing in beginning and recovering from turns.
• Faulty correction for drift.
• Inadequate visual lookout for other aircraft.
