| Manufacturer: | Panstwowe Zaklady Lotnicze (PZL) Warsaw, Poland | ||||
| Crew: | One (pilot) | ||||
| Powerplant: | One PZL Bristol Mercury VS2 engine driving wooden 2-bladed Szomanski propeller, rated at 560 hp (441 kW) for take-off | ||||
Dimensions |
|||||
|---|---|---|---|---|---|
| Wingspan: | 10.72 m (35' 2") | Length: | 7.55 m (24' 9") | Height: | 2.85 m (9' 4") |
Weights |
|||||
| Empty: | 1022 kg (2256 lb) | Normal Take-off: | 1650 kg (3642 lb) | Max Take-off: | 1800 kg (3974 lb) |
Armament |
|||||
| Fixed: | Two synchronized forward-firing 7.9 mm PWU wz.33 machine guns in the fuselage and (on some aircraft) additional two wing-mounted 7.9 mm machine guns | ||||
| Disposable: | Four 12,5 kg bombs (two under each wing) | ||||
Performance |
|||||
| Maximum speed: | 375 km/h (233 mph) at 5000 m (16405 ft), 276 km/h (172 mph) at sea level. | ||||
| Cruise speed: | 250 km/h (155 mph) | ||||
| Stalling speed: | 120 km/h (74.6 mph) | ||||
| Climb: | Initial 12.4 m/s (2441 ft/min), time to 2000 m (6561 ft) 2 min 29 s. | ||||
| Service ceiling: | 8040 m (26378 ft) | ||||
| Range: | 550 km (342 miles) | ||||
